Main Features Chipset Manufacturer: Intel Chipset Model: G31 Total Processor Support: 1 Processor Socket: Socket T Processor Support: Core 2 Quad, Core 2 Duo, Pentium Dual-core, Celeron Dual-Core, Celeron Front Side Bus: 1333MHz, 1066MHz, 800MHz, 533MHz Number of Memory Slots: 2 Maximum Memory: 4GB Memory Standard: DDR2-800/PC2-6400, DDR2-667/PC2-5300, DDR2-533/PC2-4200 Memory Technology: DDR2 SDRAM IDE Controller: Yes IDE Standard: Ultra ATA/100 (ATA-6) Floppy Controller: Yes SATA Controller: Yes SATA Standard: Serial ATA/300 Onboard Video: Yes Graphics Controller Manufacturer: Intel Graphics Controller Model: GMA 3100 Sound Controller Manufacturer: Realtek Sound Controller Model: ALC662 Audio Channels: 5.1 Gigabit Ethernet: Yes Expansion Slots: 1 x PCI Express x16, 1 x PCI Express x1, 2 x PCI Back Panel Interfaces: 1 x mini-DIN Keyboard, 1 x mini-DIN Mouse, 1 x DB-9 RS-232 Serial, 1 x DB-25 IEEE 1284 Parallel, 1 x HD-15 VGA, 4 x Type A USB 2.0 USB, 1 x RJ-45 Network, 1 x Mini-phone Audio Line In, 1 x Mini-phone Audio Line Out, 1 x Mini-phone Microphone Front Panel Interfaces: 1 x HDD LED, 1 x Power LED, 1 x On/Off Switch, 1 x Reset Switch, 1 x CD-in/Aux-in Connector, 1 x Audio Header, 2 x USB Header, 1 x S/PDIF Out, 1 x Speaker Number of IDE Interfaces: 1 Number of SATA Interfaces: 4 Form Factor: Micro ATX Dimensions: 9.6" Width x 8" Depth Additional Information: 1600MHz is an overclocking memory <p> <b>BIOS Features:</b> 8Mb flash EEPROM w/ LAN Boot PnP ACPI WfM DMI </p> <p> <b>Support Disc Contents:</b> WHQL Drivers Adobe Reader 7.07 Direct x 9.0 Norton 2006 </p> Marketing Information Based on the Intel G31 chipset, and supporting the latest Intel Core 2 Quad and Core 2 Duo processors up to 1600MHz(via overclocking) FSB, the G31MXP unlocks the latest processing power for the integrated desktop market. Package Content G31MXP-K Desktop Board Support Disc
