Lens
Mount
|
|
Nikon F
bayonet mount
|
|
Angle
|
|
Equivalent
to angle produced by lens focal length (1/5 times when DX format is selected)
|
|
Effective
Pixels
|
|
12.1
million
|
|
Sensor
Size
|
|
36.0 x
23.9mm
|
|
Sensor Format
|
|
FX
|
|
Sensor Type
|
|
CMOS
|
|
Total
Pixels
|
|
12.87
million
|
|
Dust-Off
Reference Photo
|
|
Yes
|
|
Area (pixels)
|
FX-format
(L) 4256 x 2832
(M) 3184 x 2120
(S) 2128 x 1416
1:2 format (30 x 20)
(L) 3,552 x 2,368
(M) 2,656 x 1,776
(S) 1,776 x 1,184
5:4 format (30 x 24)
(L) 3552 x 2832
(M) 2656 x 2120
(S) 1776 x 1416
DX-format
(L) 2784 x 1848
(M) 2080 x 1384
(S) 1392 x 920
|
|
File
Format
|
Uncompressed
12/14-bit NEF (RAW)
Compressed 12/14-bit NEF (RAW, Lossless compressed): approx. 60-80 percent
Compressed 12/14-bit NEF (RAW, Compressed): approx. 45-60 percent
JPEG: JPEG-baseline-compliant; can be selected from Size Priority and Optimal
Quality
TIFF (RGB)
WAV
|
|
Control
|
Monochrome
Neutral
Nine User-customizable Settings
Standard
Vivid
|
|
Storage
Media
|
|
CompactFlash©
(Type I, compliant with UDMA)
|
|
Card
Slot
|
|
2
CompactFlash© cards
|
|
File
System
|
Compliant
with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.21 (Exchangeable Image File Format for Digital Still Cameras
|
|
Viewfinder
|
|
SLR-type
with fixed eye-level pentaprism
|
|
Viewfinder
Frame Coverage
|
|
100%
Approx.
|
|
Viewfinder
Magnification
|
|
0.70x
Approx.
|
|
Viewfinder
Eyepoint
|
|
18mm
(-1.0m⁻¹)
|
|
Focusing
Screen
|
|
BriteView
Clear Matte VI - Type B
|
|
Interchangeable
Focusing Screens
|
BriteView
Clear Matte VI - Type B
Clear Matte VI - Type E
|
|
Reflex
Mirror
|
|
Quick-return
type
|
|
Lens
Aperture
|
|
Instant-return
type with depth-of-field preview button
|
|
Depth-of-field
Control
|
|
Yes
|
|
Lens
Compatibility at a Glance
|
AF-S or
AF lenses fully compatible
Metering with AI lenses
|
|
Compatible
Lenses
|
AF NIKKOR
other than type G or D*2: All functions supported except 3D Color Matrix
Metering II
AI-P NIKKOR: All functions supported except autofocus and 3D Color Matrix
Metering II
DX AF NIKKOR: All functions supported except FX-format (36x24)/5:4 (30x24)
image size
Non-CPU AI NIKKOR: Can be used in exposure modes A and M; Electronic
Rangefinder can be used if maximum aperture is f/5.6 or faster; Color Matrix
Metering and aperture value display supported if user provides lens data
Type G or D AF NIKKOR: All functions supported
|
|
Shutter
type
|
|
Electronically
controlled vertical-travel focal-plane
|
|
Fastest
Shutter Speed
|
1/8000
sec. in steps of 1/3
1/2
1 EV
|
|
Slowest
Shutter Speed
|
30 sec.
in steps of 1/3
1/2
1 EV
|
|
Flash
Sync Speed
|
|
Up to
1/250 sec.
|
|
Bulb
Shutter Setting
|
|
Yes
|
|
Shutter
Release Modes
|
Continuous
low-speed [CL] mode; 1-9 frames per second
Continuous high-speed [CH] mode; 9 frames per second (9-11 frames per second
with DX format)
Live View [LV] mode
Mirror-up [Mup] mode
Self-timer mode
Single-frame [S] mode
|
|
Continuous
Shooting Options
|
FX-format
CH: Up to 9 frames per second
CL: Up to 8 frames per second
5:4 format
CH: Up to 9 frames per second
CL: Up to 8 frames per second
DX-format
CH: Up to 11 frames per second
CL: Up to 10 frames per second
|
|
Top
Continuous Shooting Speed at full resolution
|
|
9 frames
per second
|
|
Self-timer
|
|
2, 5, 10,
20 sec. Timer duration electronically controlled
|
|
Exposure
Metering System
|
1,005-pixel
RGB sensor 3D Color Matrix Metering II
Spot AF
Variable Center-weighted
Spot meter centered on selected focus
point (on center focus point when non-CPU lens is used)
|
|
Metering Range
|
0 to 20
EV (Matrix or center-weighted metering at ISO 100 equivalent, f/1.4 lens, at
20°C/68°F)
2 to 20 EV (Spot metering at ISO 100 equivalent, f/1.4 lens at 20°C/68°F)
|
|
Exposure
Meter Coupling
|
CPU
AI
|
|
Exposure
Modes
|
Aperture-Priority
Auto (A)
Manual (M)
Programmed Auto with flexible Program (P)
Shutter-Priority Auto (S)
|
|
Exposure
Compensation
|
±5 EV in
increments of 1/3
1/2
1
|
|
Exposure
Bracketing
|
|
From 2 to
9 exposures in increments of 1/3, 1/2, 2/3 or 1 EV
|
|
Exposure
Lock
|
Yes
Luminosity locked at detected value with AE-L/AF-L button
|
|
Mirror
Lock Up
|
|
Yes
|
|
ISO
Sensitivity
|
ISO 200 -
12,800
Lo-1 (ISO 100)
Hi-1 (ISO 25,600)
Hi-2 (ISO 51,200)
Hi-3 (ISO 102,400)
|
|
Lowest
Standard ISO Sensitivity
|
200 in
steps of 1/3
1/2
1 EV
|
|
Highest
Standard ISO Sensitivity
|
12,800 in
steps of 1/3
1/2
1 EV
|
|
Lowest
Expanded ISO Sensitivity
|
|
ISO 100
equivalent, in steps of 1/3, 1/2, 1 EV
|
|
Highest
Expanded ISO Sensitivity
|
|
Hi-3 (ISO
102,400 equivalent)
|
|
Expanded
ISO Sensitivity Options
|
Hi-1
(ISO-25,600 equivalent) in 1/3, 1/2 or 1 EV
Hi-2, (ISO-51,200 equivalent), 1 EV
Hi-3, (ISO-102,400 equivalent), 1 EV
|
|
Long
Exposure Noise Reduction
|
|
Yes
|
|
High
ISO Noise Reduction
|
Low
Normal
High
Off
|
|
Single-point
AF Mode
|
|
Yes
|
|
Dynamic
AF Mode
|
|
Number of
AF points: 9, 21, 51 and 51 (3D-tracking)
|
|
Auto-area
AF Mode
|
|
Yes
|
|
Autofocus
System
|
51 focus
points (15 cross-type sensors)
AF fine adjustment possible
Autofocus TTL phase detection
Detection range: EV -1 to EV +19 (ISO 100 equivalent, at normal temperature:
20°C/68°F)
Focal-plane contrast [in LiveView (Tripod) mode]
Nikon Multi-CAM 3500FX autofocus module
|
|
Focus
Lock
|
AE-L/AF-L
button
Half press of shutter-release button (single-point AF in AF-S)
|
|
Focus
Modes
|
Continuous-servo
(C)
Manual
Single-servo AF (S)
|
|
Maximum
Autofocus Areas/Points
|
|
51
|
|
Autofocus
Fine Tune
|
|
Yes
|
|
Flash
Bracketing
|
|
2 to 9
exposures in increments of 1/3, 1/2, 2/3 or 1 EV
|
|
X-Sync
Speed
|
|
1/250
|
|
Top
FP High Speed Sync
|
|
Up to
1/8000
|
|
Flash
Control
|
|
i-TTL
Balanced fill-flash, standard i-TTL flash for digital SLR
|
|
Flash
Sync Modes
|
Front-curtain
sync (normal)
Slow sync
Rear-curtain sync
Red-eye reduction
Red-eye reduction with slow sync
|
|
Accessory
Shoe
|
|
Yes
|
|
Nikon
Creative Lighting System (CLS)
|
|
CLS
Supported
|
|
Flash
Sync Terminal
|
|
Yes
|
|
White
Balance
|
Auto (2
types)
Auto (TTL white balance with 2,016-pixel RGB sensor)
Cloudy
Direct Sunlight
Fine Tune by Kelvin color temperature setting (2,500 K to 10,000K)
Flash
Fluorescent (7 types)
Incandescent
Preset manual (up to 5 values can be stored)
Seven manual modes with fine-tuning
Shade
|
|
White
Balance Bracketing
|
|
2 to 9
exposures
|
|
Live
View Shooting
|
Handheld
mode
Tripod mode
|
|
Movie
Audio recording device
|
|
Built-in
monaural microphone
|
|
Movie
|
HD
1280x720 / 24 fps
VGA 640x424 / 24 fps
QVGA 320x216 / 24fps
Movie with sound
|
|
Movie
Audio
|
|
Built-in
microphone, monaural
|
|
Monitor
Size
|
|
3.0 in.
diagonal
|
|
Monitor
Resolution
|
|
921,000
Dots
|
|
Monitor
Type
|
Super
Density
Wide Viewing Angle TFT-LCD
|
|
Monitor
Angle of View
|
|
170-degree
wide-viewing angle
|
|
Monitor
Adjustments
|
|
Brightness,
7 levels
|
|
Virtual
Horizon Camera Indicator
|
|
Yes
|
|
Playback
Functions
|
Auto
image rotation
Full frame
Highlight point display
Histogram display
Image Comment
Movie Playback
Shooting data
Slideshow
Thumbnail (4, 9 or 72 segments)
Voice Memo
Zoom
|
|
In-Camera
Image Editing
|
Color
Balance
D-Lighting
Edit Movie with Save Selected Frame
Filter Effects
Image Overlay
Monochrome
NEF (RAW) Processing
Red-eye Correction
Resize
Side-by-Side Comparison
Trim
|
|
Comment
|
Yes
Up to 36 characters
|
|
Voice
Memo Function
|
|
Yes
|
|
Interface
|
10-pin
Terminal
HDMI
Hi-speed USB
NTSC
PAL
|
|
WiFi
Functionality
|
|
FTP file
transfer available and PTP/IP with optional WT-4A (IEEE 802.11 a/b/g)
|
|
GPS
|
|
GP-1 GPS
unit
|
|
Save/Load
Camera settings
|
|
Yes
|
|
Total
custom Settings
|
|
46
|
|
My
Menu
|
|
Yes with
customization
|
|
Supported
Languages
|
Chinese
(Simplified and Traditional)
Dutch
English
Spanish
Finnish
French
Italian
German
Japanese
Korean
Polish
Portuguese
Russian
Swedish
|
|
Date,
Time and Daylight Savings Time Settings
|
|
Yes
|
|
World
Time Setting
|
|
Yes
|
|
Battery
|
|
Rechargeable
|
|
Battery / Batteries
|
EN-EL4
Lithium-ion Battery
EN-EL4a Lithium-ion Battery
|
|
Battery Life (shots per charge)
|
|
4,200
shots (CIPA)
|
|
AC
Adapter
|
|
EH-6 AC
Adapter
|
|
Battery Charger
|
MH-21
Quick Charger
MH-22 Quick Charger
|
|
Tripod
Socket
|
|
1/4 inch
20
|
|
Approx.
Dimensions
|
Width 6.3
in. (159.5mm)
Height 6.2 in. (157mm)
Depth 3.4 in. (87.5mm)
|
|
Approx.
Weight
|
43.7 oz.
(1,240g)
camera body only
|
|
Supplied
Software
|
|
Software
Suite CD-ROM
|
