Lens
Mount
|
|
Nikon F
bayonet mount
|
|
Angle
|
|
Effective
picture angle 1.5x (Approx.) conversion factor (Nikon DX format)
|
|
Effective
Pixels
|
|
16.2
million
|
|
Sensor
Size
|
|
23.6 x
15.6mm
|
|
Sensor Format
|
|
DX
|
|
Sensor Type
|
|
CMOS
|
|
Total
Pixels
|
|
16.9
million
|
|
Dust-reduction
system
|
|
sensor cleaning
|
|
Area (pixels)
|
DX-format
(L) 4928 x 3264
(M) 3696 x 2448
(S) 2464 x 1632
|
|
File
Format
|
Compressed
14-bit NEF (RAW)
JPEG (Baseline Compliant)
MOV
|
|
Control
|
Landscape
Monochrome
Neutral
Portrait
Standard
User-customizable Settings
Vivid
|
|
Storage
Media
|
SD
SDHC
SDXC
|
|
Card
Slot
|
|
1 Secure
Digital (SD)
|
|
File
System
|
Compliant
with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras
|
|
Viewfinder
|
|
Eye-level
pentamirror single-lens reflex viewfinder
|
|
Viewfinder
Frame Coverage
|
|
95%
Approx.
|
|
Viewfinder
Magnification
|
|
0.78x
Approx.
|
|
Viewfinder
Eyepoint
|
|
17.9mm
|
|
Viewfinder
Diopter Adjustment
|
|
-1.7 to
+0.7 m¯¹
|
|
Focusing
Screen
|
|
Type B
BriteView Clear Matte Mark VII screen
|
|
Reflex
Mirror
|
|
Quick-return
type
|
|
Lens
Aperture
|
|
Instant-return
type
|
|
Lens
Compatibility at a Glance***
|
|
AF-S Lens
Required for Autofocus
|
|
Compatible
Lenses
|
AF-S,
AF-I: All functions supported
AI-P NIKKOR: All functions supported except 3D color matrix metering II
IX NIKKOR lenses can not be used
Non-CPU: Can be used in mode M, but exposure meter does not function;
Electronic Rangefinder can be used if maximum aperture is f/5.6 or faster
Other AF NIKKOR (Excluding lenses for F3AF): All functions supported except
3D color matrix metering II
Type G or D AF NIKKOR not equipped with an autofocus motor: All functions
supported except autofocus
Type D PC NIKKOR: All functions supported except autofocus and some shooting
modes.
|
|
Shutter
type
|
|
Electronically
controlled vertical-travel focal-plane
|
|
Shutter
Speed
|
|
1/4000 to
30 sec. in steps of 1/3 EV
|
|
Fastest
Shutter Speed
|
1/4000
sec. in steps of 1/3
1/2
1 EV
|
|
Slowest
Shutter Speed
|
30 sec. in
steps of 1/3
1/2
1 EV
|
|
Flash
Sync Speed
|
|
Up to
1/200 sec.
|
|
Bulb
Shutter Setting
|
|
Yes
|
|
Shutter
Release Modes
|
Continuous
Delayed remote
Quick Response Remote Mode
Quiet shutter-release
Self-timer mode
Single-frame [S] mode
|
|
Top
Continuous Shooting Speed at full resolution
|
|
4 frames
per second
|
|
Self-timer
|
|
2, 5, 10,
20 sec. Timer duration electronically controlled
|
|
Exposure
Metering System
|
|
TTL
exposure metering using 420-pixel RGB sensor
|
|
Metering
Method
|
|
Matrix: 3D
color matrix metering II (type G and D lenses); color matrix metering II
(other CPU lenses)
|
|
Metering
Range
|
0 to 20 EV
(3D color matrix or center-weighted metering)
2 to 20 EV (spot metering)
|
|
Exposure
Meter Coupling
|
|
CPU
|
|
Exposure
Modes
|
Advanced
Scene Modes
Aperture-Priority (A)
Auto
Auto (flash off)
Manual (M)
Programmed Auto with flexible Program (P)
Shutter-Priority Auto (S)
Special Effects Mode
|
|
Scene
Modes
|
Autumn Colors
Beach / Snow
Blossom
Candlelight
Child
Close-up
Dusk / Dawn
Food
Landscape
Night Landscape
Night Portrait
Party / Indoor
Pet Portrait
Portrait
Sports
Sunset
|
|
Exposure
Compensation
|
|
±5 EV in
increments of 1/3 or 1/2 EV
|
|
Exposure
Bracketing
|
|
3 frames
±2 EV in 1/3 or 1/2 steps
|
|
Exposure
Lock
|
|
Yes
|
|
Mirror
Lock Up
|
|
Yes (for
image sensor cleaning)
|
|
ISO
Sensitivity
|
ISO 100 -
6400
Hi-0.3
Hi-0.7
Hi-1 (ISO 12,800)
Hi-2 (ISO 25,600)
|
|
Lowest
Standard ISO Sensitivity
|
|
100
|
|
Highest
Standard ISO Sensitivity
|
|
6400
|
|
Highest
Expanded ISO Sensitivity
|
|
HI-2 (ISO
25,600 equivalent)
|
|
Long
Exposure Noise Reduction
|
|
Yes
|
|
High
ISO Noise Reduction
|
Low
Normal
High
Off
|
|
Active
D-Lighting
|
|
On
|
|
D-Lighting
Bracketing
|
|
2
exposures
|
|
Single-point
AF Mode
|
|
Yes
|
|
Dynamic
AF Mode
|
|
Number of
AF points: 11 (3D-tracking)
|
|
Auto-area
AF Mode
|
|
Yes
|
|
Autofocus
System
|
|
Nikon
Multi-CAM 1000 autofocus sensor module with TTL phase detection
|
|
Lens
Servo
|
|
Autofocus
(AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); auto AF-S/AF-C
selection (AF-A); predictive focus tracking activated automatically according
to subject status
|
|
Focus
Point
|
|
Can be
selected from 11 focus points
|
|
Focus
Lock
|
|
Focus can
be locked by pressing shutter-release button halfway (single-servo AF)
|
|
Focus
Modes
|
Auto
AF-S/AF-C selection (AF-A)
Continuous-servo (AF-C)
Face-Priority AF available in Live View only and D-Movie only
Full-time Servo (AF-A) available in Live View only
Manual focus (M): Electronic rangefinder can be used
Normal area
Single-servo AF (AF-S)
Wide area
|
|
Maximum
Autofocus Areas/Points
|
|
11
|
|
Autofocus
Sensitivity
|
|
-1 to +19
EV (ISO 100, 20°C/68°F)
|
|
Built-in
Flash
|
|
Yes
|
|
Guide
Number
|
|
Approx.
39/12, 43/13 with manual flash (ft/m, ISO 100, 68°F/20°C)
|
|
Flash
Control
|
Auto
aperture: Available with SB-900/SB-800 and CPU lens
Distance priority manual: Available with SB-900, SB-800 and SB-700
i-TTL Balanced fill-flash, standard i-TTL flash for digital SLR
Non-TTL auto: Supported flash units include SB-900, SB-800, SB-80DX, SB-28DX,
SB-28, SB-27, and SB-22S
|
|
Flash
Sync Modes
|
Front-curtain
sync (normal)
Slow sync
Rear-curtain sync
Red-eye reduction
Red-eye reduction with slow sync
|
|
Flash
Compensation
|
|
-3 to +1
EV in increments of 1/3 or 1/2 EV
|
|
Accessory
Shoe
|
|
Yes
|
|
Nikon
Creative Lighting System (CLS)
|
|
CLS
Supported
|
|
White
Balance
|
Auto
Cloudy
Direct Sunlight
Flash
Fluorescent (7 types)
Incandescent
Preset Manual
Shade
|
|
White
Balance Bracketing
|
|
3
exposures
|
|
Live
View Shooting
|
|
Yes
|
|
Live
View Lens servo
|
|
Autofocus
(AF): Single-servo AF (AF-S); full-time-servo AF (AF-F)
|
|
Live
View AF-area mode
|
Face-priority
AF
Wide-area AF
Normal-area AF
Subject-tracking AF
|
|
Live
View Scene Auto Selector
|
|
Auto mode
|
|
Movie
Metering
|
|
TTL
exposure metering using main image sensor
|
|
Movie
Maximum recording time
|
|
20 min.
|
|
Movie
File Format
|
|
MOV
|
|
Movie
Video Compression
|
|
H.264/MPEG-4
Advanced Video Coding
|
|
Movie
Audio recording format
|
|
Linear PCM
|
|
Movie
|
HD
1,920x1,080 / 30 fps
HD 1,920×1,080 / 24 fps
HD 1,280×720 / 30 fps
HD 1,280×720 / 24 fps
VGA 640×424 / 30 fps
|
|
Movie
Audio
|
Built-in
microphone, monaural
Optional external stereo mini-pin jack (3.5mm diameter)
|
|
Monitor
Size
|
|
3.0 in.
diagonal
|
|
Monitor
Resolution
|
|
921,000
Dots
|
|
Monitor
Type
|
Wide
Viewing Angle
Vari-angle TFT-LCD
|
|
Monitor
Angle of View
|
|
170-degree
wide-viewing angle
|
|
|
|
Monitor
Adjustments
|
|
Brightness,
7 levels
|
|
Playback
Functions
|
Auto image
rotation
Calendar
Full frame
Highlight point display
Histogram display
Movie Playback
Shooting data
Slideshow
Sound playback
Thumbnail (4, 9 or 72 images)
Zoom
|
|
In-Camera
Image Editing
|
Color
Balance
Color Outline
Color Sketch
D-Lighting
Distortion Control
Edit Movie
Filter Effects
Fisheye
Image Overlay
Miniature Effect
Monochrome
NEF (RAW) Processing
Perspective Control
Quick Retouch
Red-eye Correction
Resize
Side-by-Side Comparison
Straighten
Trim
|
|
Comment
|
|
Yes
|
|
Interface
|
Audio/Video
out
HDMI output: Type C mini-pin HDMI connector
Hi-speed USB
NTSC
Stereo Microphone Input
|
|
WiFi
Functionality
|
|
Eye-Fi
Compatible
|
|
GPS
|
|
GP-1 GPS
unit
|
|
Total
custom Settings
|
|
20
|
|
My
Menu
|
|
Yes with
customization
|
|
Recent
Settings
|
|
Yes
|
|
Supported
Languages
|
Arabic
Chinese (Simplified and Traditional)
Danish
Dutch
English
Spanish
Finnish
French
Italian
German
Indonesian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Swedish
Czech
Norweigan
Thai
Turkish
|
|
Date,
Time and Daylight Savings Time Settings
|
|
Yes
|
|
World
Time Setting
|
|
Yes
|
|
Battery
/ Batteries
|
|
EN-EL14 Rechargeable Li-ion Battery
|
|
Battery
Life (shots per charge)
|
|
660 shots
(CIPA)
|
|
AC
Adapter
|
|
EH-5a AC
Adapter
|
|
Battery
Charger
|
|
MH-24
Quick Charger
|
|
Tripod
Socket
|
|
1/4 in. (ISO1222)
|
|
Approx.
Dimensions
|
Width 5.0
in. (127mm)
Height 3.8 in. (96.5mm)
Depth 3.1 in. (78.7mm)
|
|
Approx.
Weight
|
19.7 oz.
(560g)
camera body only
|
|
Supplied
Software
|
|
ViewNX 2
CD-ROM
|
