Lens
Mount
|
|
Nikon F
bayonet mount
|
|
Angle
|
|
Effective
picture angle 1.5x (Approx.) conversion factor (Nikon DX format)
|
|
Effective
Pixels
|
|
16.2
million
|
|
Sensor
Size
|
|
23.6 x
15.6mm
|
|
Sensor Format
|
|
DX
|
|
Sensor Type
|
|
CMOS
|
|
Total
Pixels
|
|
16.9
million
|
|
Dust-Off
Reference Photo
|
|
Yes
|
|
Area (pixels)
|
DX-format
(L) 4928 x 3264
(M) 3696 x 2448
(S) 2464 x 1632
|
|
File
Format
|
NEF (RAW):
lossless compressed or compressed 12 or 14 bit
JPEG: JPEG-baseline-compliant; can be selected from Size Priority and Optimal
Quality
MOV
|
|
Control
|
Landscape
Monochrome
Neutral
Nine User-customizable Settings
Portrait
Standard
Vivid
|
|
Storage
Media
|
SD
SDHC
SDXC
|
|
Card
Slot
|
|
2 Secure
Digital (SD)
|
|
File
System
|
Compliant
with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras
|
|
Viewfinder
|
|
Eye-level
pentaprism single-lens reflex viewfinder
|
|
Viewfinder
Frame Coverage
|
|
100%Approx.
|
|
Viewfinder
Magnification
|
|
0.95x
Approx.
|
|
Viewfinder
Eyepoint
|
|
19.5mm
|
|
Viewfinder
Diopter Adjustment
|
|
-3 to +1m⁻¹
|
|
Focusing
Screen
|
|
Type B
BriteView Clear Matte Mark II with AF area brackets (grid lines can be
displayed)
|
|
Reflex
Mirror
|
|
Quick-return
type
|
|
Depth-of-field
Control
|
|
Yes
|
|
Lens
Compatibility at a Glance***
|
AF-S or AF
lenses fully compatible
Metering with AI lenses
|
|
Compatible
Lenses
|
AF-NIKKOR
for F3AF not supported
AI-P NIKKOR: All functions supported except 3D color matrix metering II
DX AF NIKKOR: All functions possible
Electronic rangefinder can be used if maximum aperture is f/5.6 or faster
IX Nikkor lenses cannot be used
Non-CPU: Can be used in modes A and M; color matrix metering and aperture
value display supported if user provides lens data (AI lenses only)
Other AF NIKKOR: All functions supported except 3D color matrix metering II
PC Micro-NIKKOR does not support some functions
Type G or D AF NIKKOR: All functions supported
|
|
Shutter
type
|
|
Electronically
controlled vertical-travel focal-plane
|
|
Fastest
Shutter Speed
|
1/8000
sec. in steps of 1/3
1/2
1 EV
|
|
Slowest
Shutter Speed
|
30 sec. in
steps of 1/3
1/2
1 EV
|
|
Flash
Sync Speed
|
Up to
1/250 sec.
Synchronizes with shutter at 1/320s or slower (flash range drops at speeds
between 1/250 and 1/320s)
|
|
Bulb
Shutter Setting
|
|
Yes
|
|
Shutter
Release Modes
|
Continuous
low-speed [CL] mode; 1-5 frames per second
Continuous high-speed [CH] mode; 6 frames per second
Live View [LV] mode
Self-timer mode
Single-frame [S] mode
|
|
Continuous
Shooting Options
|
DX-format
CH: Up to 6 frames per second
CL: Up to 5 frames per second
|
|
Top
Continuous Shooting Speed at full resolution
|
6 frames
per second
(CIPA guidelines)
|
|
Self-timer
|
|
2, 5, 10,
20 sec. Timer duration electronically controlled
|
|
Exposure
Metering System
|
|
TTL
exposure metering using 2,016-pixel RGB sensor
|
|
Metering
Range
|
0 to 20 EV
(Matrix or center-weighted metering at ISO 100 equivalent, f/1.4 lens, at
20°C/68°F)
2 to 20 EV (Spot metering at ISO 100 equivalent, f/1.4 lens at 20°C/68°F)
|
|
Exposure
Meter Coupling
|
CPU
AI
|
|
Exposure
Modes
|
Advanced
Scene Modes
Aperture-Priority Auto (A)
Auto
Auto (flash off)
Manual (M)
Programmed Auto with flexible Program (P)
Shutter-Priority Auto (S)
U1 (user setting 1)
U2 (user setting 2)
|
|
Scene
Modes
|
Autumn Colors
Beach / Snow
Blossom
Candlelight
Child
Close-up
Dusk / Dawn
Food
High Key
Landscape
Low Key
Night Landscape
Night Portrait
Party / Indoor
Pet Portrait
Portrait
Silhouette
Sports
Sunset
|
|
Exposure
Compensation
|
|
±5 EV in
increments of 1/3 or 1/2 EV
|
|
Exposure
Bracketing
|
|
2 to 3
frames in steps of 1/3, 1/2, 2/3, 1 or 2 EV
|
|
Exposure
Lock
|
|
Yes
|
|
Mirror
Lock Up
|
|
Yes
|
|
ISO
Sensitivity
|
ISO 100 -
6400
Hi-1 (ISO 12,800)
Hi-2 (ISO 25,600)
|
|
Lowest
Standard ISO Sensitivity
|
100 in
steps of 1/3
1/2
1 EV
|
|
Highest
Standard ISO Sensitivity
|
6400 in
steps of 1/3
1/2
1 EV
|
|
Highest
Expanded ISO Sensitivity
|
|
HI-2 (ISO
25,600 equivalent)
|
|
Expanded
ISO Sensitivity Options
|
Hi-1
(ISO-12,800 equivalent) in 1/3, 1/2 or 1 EV
Hi-2 (ISO 25600 equivalent)
|
|
Long
Exposure Noise Reduction
|
|
Yes
|
|
High
ISO Noise Reduction
|
Low
Normal
High
Off
|
|
D-Lighting
Bracketing
|
|
2 or 3
exposures
|
|
Single-point
AF Mode
|
|
Yes
|
|
Dynamic
AF Mode
|
|
Number of
AF points: 9, 21, 39 and 39 (3D-tracking)
|
|
Auto-area
AF Mode
|
|
Yes
|
|
Autofocus
System
|
39 focus
points (including 9 cross-type sensors)
AF-assist illuminator (range approx. 1 ft. 8in.-9 ft. 10 in.)
Finetuning
Nikon Multi-CAM 4800DX autofocus sensor module with TTL phase detection
|
|
Focus
Lock
|
AE-L/AF-L
button
Half press of shutter-release button (single-point AF in AF-S)
|
|
Focus
Modes
|
Auto
AF-S/AF-C selection (AF-A)
Continuous-servo (AF-C)
Face-Priority AF
Full-time Servo (AF-A) available in Live View only
Normal area
Single-servo AF (AF-S)
Wide area
|
|
Maximum
Autofocus Areas/Points
|
|
39
|
|
Autofocus
Sensitivity
|
|
-1 to +19
EV (ISO 100, 20°C/68°F)
|
|
Built-in
Flash
|
|
Yes
|
|
Flash
Bracketing
|
|
2 to 3
frames in steps of 1/3, 1/2, 2/3, 1 or 2 EV
|
|
Built-in
Flash Distance
|
|
39 (ISO
100) ft.
|
|
Top
FP High Speed Sync
|
|
Up to
1/8000
|
|
Flash
Control
|
|
i-TTL Balanced
fill-flash, standard i-TTL flash for digital SLR
|
|
Flash
Sync Modes
|
Front-curtain
sync (normal)
Slow sync
Rear-curtain sync
Red-eye reduction
Red-eye reduction with slow sync
|
|
Flash
Compensation
|
|
-3 to +1
EV in increments of 1/3 or 1/2 EV
|
|
Accessory
Shoe
|
|
Yes
|
|
Nikon
Creative Lighting System (CLS)
|
Built-in
flash Commander Mode
CLS Supported
|
|
White
Balance
|
Auto (2
types)
Auto (TTL white balance with 2,016-pixel RGB sensor)
Cloudy
Direct Sunlight
Fine Tune by Kelvin color temperature setting (2,500 K to 10,000K)
Flash
Fluorescent (7 types)
Incandescent
Preset manual (up to 5 values can be stored)
Seven manual modes with fine-tuning
Shade
|
|
White
Balance Bracketing
|
|
2 or 3
exposures
|
|
Live
View Shooting
|
|
Yes
|
|
|
|
Movie
|
HD
1,920×1,080 / 24 fps
HD 1,280×720 / 30 fps
HD 1,280×720 / 24 fps
VGA 640×424 / 30 fps
Movie with sound
|
|
Movie
Audio
|
Built-in
microphone, monaural
Optional external stereo mini-pin jack (3.5mm diameter)
Microphone sensitivity can be adjusted
|
|
Monitor
Size
|
|
3.0 in.
diagonal
|
|
Monitor
Resolution
|
|
921,000
Dots
|
|
Monitor
Type
|
Super
Density
Wide Viewing Angle TFT-LCD
|
|
Monitor
Angle of View
|
|
170-degree
wide-viewing angle
|
|
Monitor
Adjustments
|
|
Brightness,
7 levels
|
|
Virtual
Horizon Camera Indicator
|
|
Yes
|
|
Playback
Functions
|
Auto image
rotation
Calendar
Full frame
Highlight point display
Histogram display
Movie Playback
Shooting data
Slideshow
Sound playback
Thumbnail (4, 9 or 72 segments)
Zoom
|
|
In-Camera
Image Editing
|
Color
Balance
Color Outline
D-Lighting
Distortion Control
Edit Movie
Filter Effects
Fisheye
Image Overlay
Miniature Effect
Monochrome
NEF (RAW) Processing
Perspective Control
Quick Retouch
Red-eye Correction
Resize
Side-by-Side Comparison
Straighten
Trim
|
|
Comment
|
|
Yes
|
|
Interface
|
Audio/Video
out
HDMI
Hi-speed USB
NTSC
PAL
Stereo Microphone Input
|
|
WiFi
Functionality
|
Eye-Fi
Compatible
FTP file transfer available and PTP/IP with optional WT-4A (IEEE 802.11
a/b/g)
|
|
GPS
|
|
GP-1 GPS
unit
|
|
Save/Load
Camera settings
|
|
Yes
|
|
My
Menu
|
|
Yes with
customization
|
|
Recent
Settings
|
|
Yes
|
|
Supported
Languages
|
Arabic
Chinese (Simplified and Traditional)
Danish
Dutch
English
Spanish
Finnish
French
Italian
German
Indonesian
Japanese
Korean
Polish
Portuguese
Russian
Swedish
Czech
Norweigan
Thai
Turkish
|
|
Date,
Time and Daylight Savings Time Settings
|
|
Yes
|
|
World
Time Setting
|
|
Yes
|
|
Battery
|
|
Rechargeable
|
|
Battery / Batteries
|
|
EN-EL15
Lithium-ion Battery
|
|
Battery Life (shots per charge)
|
|
1,050
shots (CIPA)
|
|
AC
Adapter
|
|
EH-5a AC
Adapter
|
|
Battery Charger
|
|
MH-25
Quick Charger
|
|
Tripod
Socket
|
|
1/4 inch
20
|
|
Approx.
Dimensions
|
Width 5.2
in. (132mm)
Height 4.1 in. (103mm)
Depth 3.0 in. (77mm)
|
|
Approx.
Weight
|
24.3 oz.
(690g)
camera body only
|
