General

• Recommended Use Small business,
  Corporate business
• Built-in Devices Display,
  Keyboard,
  Touchpad,
  Stereo speakers,
  Microphone
• Width 12.5 in
• Depth 10.1 in
• Height 1.7 in
• Weight 7.1 lbs
• Color Black
• Localization English / United States
• Notebook type Mid-size laptops (6-7.5 lbs.)

Processor

• Processor Intel Pentium III 850.0 MHz
• Data Bus Speed 100.0 MHz

Cache Memory

• Type L2 cache - Advanced Transfer Cache
• Installed Size 256.0 KB

RAM

• Installed Size 128.0 MB / 512.0 MB (max)
• Technology SDRAM - 100.0 MHz
• Form Factor SO DIMM 144-pin

Environmental Parameters

• Min Operating Temperature 50.0 �F
• Max Operating Temperature 95.0 �F
• Humidity Range Operating 10 - 90%
• Shock Tolerance 10.0 g @ 11ms half-sine pulse (operating) / 60.0 g @ 11ms half-sine pulse (non-operating)
• Vibration Tolerance 0.5 g @ 10-500 Hz (operating) / 1.0 g @ 10-500 Hz (non-operating)
• Max Altitude Operating 9840.0 ft

Storage Controller

• Storage controller type IDE

Flash Memory

• Type None

Storage

• Floppy Drive 3.5" 1.44 MB floppy - Plug-in module
• Hard Drive 20.0 GB
• Storage Removable None
• Hard drive type Portable

Optical Storage

• Type 1.0 x DVD-ROM - Plug-in module
• Read Speed 8x
• Compliant Standards 2nd generation,
  CD-XA,
  CDi,
  Kodak PhotoCD,
  CD-DA

Display

• Display Type 15.0 in TFT active matrix Integrated
• Max Resolution 1400 x 1050 ( SXGA+ )
• Widescreen Display No
• Color Support 24-bit (16.7 million colors)

Video

• Graphics Processor / Vendor AGP 2x - ATI RAGE Mobility P
• Video Memory 8.0 MB SDRAM
• Supported Display Graphics XGA (1024x768),
  SVGA (800x600),
  VGA (640x480),
  SXGA+ (1400x1050),
  UXGA (1600x1200),
  SXGA (1280x1024),
  SXGAW (1600x1024)
• Video Output Supported NTSC,
  PAL

Audio

• Audio Output Sound card
• Signal Processor ESS Maestro-2E
• Compliant Standards DirectSound,
  Sound Blaster 16/Pro,
  Sound Blaster
• Audio Input Microphone - Integrated

Input Device(s)

• Input device type Keyboard,
  Touchpad

Telecom

• Modem Network / modem combo - Mini PCI
• Max Transfer Rate 56.0 Kbps
• Protocols & Specifications ITU V.90 , Hayes AT command set

Networking

• Networking Network adapter
• Data Link Protocol Ethernet,
  Fast Ethernet
• Compliant Standards IEEE 802.3u,
  IEEE 802.3

Expansion / Connectivity

• Expansion Bays 2.0 x Front accessible
• Expansion Slot(s) 1.0 (total) / 1.0 (free) x Memory - SO DIMM 144-pin,
  2.0 (total) / 1.0 (free) x PC Card - Type III (2 x type I / II)
• Interfaces 1.0 x Serial - Composite video output - Mini-phone mono 3.5 mm,
  1.0 x Audio - IEEE 1284 (EPP/ECP) - RJ-45,
  1.0 x USB - Line-out - IrDA,
  1.0 x Network - Ethernet 10Base-T/100Base-TX - Mini-phone stereo 3.5 mm,
  1.0 x Modem - Input - 4 pin USB Type A,
  1.0 x Parallel - RS-232C - 9 pin D-Sub (DB-9),
  1.0 x Display / video - VGA - RCA,
  1.0 x Infrared - Generic - 15 pin HD D-Sub (HD-15),
  1.0 x Keyboard / mouse - Phone line - RJ-11,
  1.0 x Display / video - 6 pin mini-DIN (PS/2 style),
  1.0 x Microphone - 25 pin D-Sub (DB-25),
  1.0 x Docking / port replicator

Miscellaneous

• Features Power-on password,
  System password

Power

• Power Device External
• Voltage Required AC 110/220 V � 10% ( 50/60 Hz )
• Power Provided 50.0 Watt
• Compliant Standards EPA Energy Star

Battery

• Technology Lithium ion
• Installed Qty 1.0 / 3.0 (max)
• Capacity 4.8 Ah
• Run Time (Up To) 3.5 hour(s)

Operating System / Software

• OS Provided Microsoft Windows Xp Edition
  Software Drivers & Utilities,
  Compaq Diagnostics,
  Compaq Insight Manager,
  Adobe Acrobat Reader,
  Compaq Power Management
