Physical Stats:
Form Factor: Extended ATX
Dimensions: 12" x 13.05" (30.5cm x 33.2cm)
Processor/Cache:CPU: ? Dual mPGA603 ZIF Sockets
? Supports up to two Intel? Xeon? processor(s) with 512KB of integrated Advanced Transfer Cache up to 3.0GHz
System Bus:400MHz system bus
System Memory:Memory Capacity: ? Eight 184-pin DIMM sockets
? Supports up to 16 GB DDR200 memory
? Dual channel memory bus
? Memory must be populated in pairs
Memory Type: ?DDR266/200 registered ECC SDRAM 72-bit, 184-pin gold-plated DIMMs
DIMM Sizes: 128 MB, 256 MB, 512 MB, 1 GB, 2 GB
Memory Voltage: 2.5 V only On-Board Devices:Chipset: ? Intel? E7500 chipset
? MCH + ICH3-S + P64H2 IPMI Support for Intelligent Platform
Management Interface v.1.5 (Optional) Network Controllers: ? Dual Port Intel? 82546EB Gigabit Ethernet
? Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Graphics: ATI Rage XL SVGA PCI video controller with 8 MB of video memory Input / Output:PCI Expansion: ? Max 2x 64-bit 133MHz PCI-X (3.3V) slots
Default: ? 2x 64-bit 100MHz PCI-X (3.3V) slot
? 4x 64-bit 66MHz PCI-X (3.3V) slots
? 1x SXB (Supermicrol Extended Bus) slot
IDE: ? Dual EIDE channels support up to four UDMA IDE devices
? Supports UDMA Mode 5, PIO Mode 4, and ATA/100
USB: Up to 5 USB ports Serial Ports: 2 Fast UART 16550 serial ports Parallel Port: 1 ECP / EEP parallel port Floppy: 1 Floppy controller; 1.44 MB, 2.88 MB, 3-mode support Keyboard / Mouse: PS/2 keyboard and mouse ports
|
