Description:

THIS IS A BUNDLE: 1 Gigabyte Ultra Durable 2 GA-G41MT-S2P Desktop Motherboard AND 1 Microsoft Windows 7 Home Premium With Service Pack 1 64-bit

GIGABYTE was the first motherboard manufacturer to realize the importance of using only the highest quality components for the critically important CPU VRM zone of the motherboard which is responsible for delivering stable power to the CPU. The GIGABYTE Ultra Durable 2 design utilizes Solid Capacitors manufactured in Japan which are rated to last for at least 50,000 hours in operational use. GIGABYTE Ultra Durable 2 motherboards also features Ferrite Core Chokes with higher energy efficiency compared to more common iron core chokes and Lower RDS(on) MOSFETs which feature lower resistance, i.e. reduced power consumption and heat. GIGABYTE has further improved on the CPU VRM area by increasing the power phases from 3 to a 4 phase design. This allows for more stable power delivery to the CPU, as well as help smooth out power ripple and noise which is important for clean CPU power delivery.

Processor & Chipset
Chipset Manufacturer:		Intel
Chipset Model:		G41 Express
Total Processor Supported:		1
Processor Technology:		Enhanced SpeedStep Technology
Processor Socket:		Socket T LGA-775
Processor Supported:		Core 2 Duo Core 2 Quad Core 2 Extreme Pentium Dual-core Celeron Dual-Core Pentium Extreme Edition Pentium 4 Pentium D Celeron Celeron D
Front Side Bus:		1333 MHz 1066 MHz 800 MHz
64-bit Processing:		Yes
Memory
Number of Memory Slots:		2
Maximum Memory:		8 GB
Memory Standard:		DDR3-1333/PC3-10600 (O.C.) DDR3-1066/PC3-8500 DDR3-800/PC3-6400
Memory Technology:		DDR3 SDRAM
I/O Controller
Controller Type:		Serial ATA/300
Video
Onboard Video:		Yes
Graphics Controller Manufacturer:		Intel
Graphics Controller Model:		GMA X4500
Audio
Sound Controller Manufacturer:		VIA
Sound Controller Model:		VT2021
Audio Channels:		7.1
Network & Communication
Gigabit Ethernet:		Yes
I/O Expansions
Number of Total Expansion Slots:		4
Number of PCI Slots:		1
Total Number of PCI Express Slots:		3
Number of PCI Express x1 Slots:		2
Number of PCI Express x16 Slots:		1
Storage
Number of SATA Interfaces:		4
Back Panel Interfaces
Total Number of USB Ports:		4
Number of USB 2.0 Ports:		4
Serial Port:		Yes
Audio Line In:		Yes
Audio Line Out:		Yes
Microphone Port:		Yes
VGA:		Yes
Network (RJ-45):		Yes
PS/2 Port:		Yes
Number of PS/2 Ports:		2
Onboard Interfaces
Total Number of Onboard USB Ports:		4
Number of Onboard USB 2.0 Ports:		4
Onboard LEDs Header:		Yes
Onboard Audio Header:		Yes
Onboard S/PDIF Header:		Yes
Power Description
Power Supply Supported:		ATX ATX12V
Physical Characteristics
Form Factor:		Micro ATX
Width:		9.6"
Depth:		7.6"

Package Contents:
Ultra Durable 2 Desktop Motherboard
Motherboard Driver Disk
2 x SATA Cables
User's Manual
I/O Shield
1 WINDOWS 7 HOME PREMIUM 64bit
