Specification:

Basic Functions	Range	Best Accuracy
Insulation Resistance	500kW ~ 10GW 1MW*~1000GW	±(5%+5)
Low Resistance	1000W	±(1%+3)
Testing Voltage	100V/250V/500V/1000V 1000V/1500V/2500V/5000V	0~20%
DC Voltage	1000V	±(1%+3)
AC Voltage	750V	±(1.5%+3)
Special Functions
Auto Ranging		V
Short Circuit Current		<1.3mA
Data Logging		18
Data Recall		V
Sleep Mode		V
Polarization index (PI)		V
Dielectric Absorption(DAR)		V
Timer	Within 30 minutes	V
Compare		V
Battery Display		V
Display Backlight	EL	V
Over Range and High Voltage Warning		V
USB		V
Max. Display Analogue Bar Graph	9999	V V

CHARACTERISTICS :

Power	UT511-1.5V Battery (R14) x 8 UT513 -1.5V Alkaline Battery (LR14) x 8
LCD Size	123 mm x 58 mm
Product Color	Grey
Product Packing Weight	3kg
Product Size	202 x 155 x 94 mm
Standard Accessories	UT513 - A pair of one plug test lead to one alligator clip, A pair of two plugs test lead to one alligator clip, Batteries, English Manual, Tool Box, USB Interfac
Optional Accessories*	Power Adapter ( NOT INCLUDED )
