SPECIFICATIONS

Basic Functions	Range	Best Accuracy
AC Voltage	20V/100V/300V/600V	(1.2%+5)
AC Current	40A/100A/400A/1000A	(2%+5)
Active Power	0.01kW-600kW	(3%+5)
Apparent Power	0.01kVA-600kVA	(3%+5)
Reactive Power	0.01kVAr-600kVAr	(4%+5)
Power Factor	0.3~1(Capacitive or Inductive )	(0.02+2)
Phase Angle	0o~360O	1O
Frequency	20Hz-500Hz
Active Energy	1~9999 kWh	(3%+2)
Temperature	-50OC~1300OC -58OF~2372OF
Special Functions
Auto Ranging
Single-phase 2-wire
3-phase 3-wire
3-phase 4-wire
True RMS	AC Voltage or Curren
Calibration Feature
Data Logging	99
Data Recall
Max/Min Mode
Data Hold
USB
Display Backlight	EL
Full Icon Display
Sleep Mode
Low Battery Display
Input Impedance for AC Voltage Measurement	Around 10MW
Max. Display	9999
Analogue Bar Graph

GENERAL CHARACTERISTICS

Power	1.5V Battery (LR6) x 4
LCD Size	46 mm x 42 mm
Product Color	Red and Grey
Product Net Weight	601g
Product Size	303 x 112 x 39 mm
Standard Accessories	UT232 - Test Lead, Batteries, User Manual, Alligator Clips, USB Interface Cable, Software, Carrying Bag
Standard Individual Packing	Gift Box
Standard Quantity Per Carton	24 pcs
Standard Carton Measurement	610 x 360 x 305 mm (0.067 CBM Per Standard Carton)
Standard Carton Gross Weight	28kg
