SPECIFICATIONS

Basic Functions	Range	Best Accuracy
AC Voltage	15V/100V/300V/600V	(1.2%+5)
AC Current	40A/100A/400A/1000A	(2%+5)
Active Power	0.01kW-600kW	(3%+5)
Apparent Power	0.01kVA~600kVA	(4%+5)
Reactive Power	0.01kVAr~600kVAr	(4%+5)
Power Factor	0.3~1	(0.02+2)
Phase Angle	0˚C~360˚C	1O
Frequency	20Hz~500Hz
Active Energy	1~9999kWh	(3%+2)
Temperature	–50˚C~1000˚C –58˚F~1832˚F
Special Functions
Auto Ranging
Single-phase 2-wire
3-phase 3-wire
3-phase 4-wire
Phase Rotation Test
True RMS	AC Voltage or Curren
Calibration Feature
Data Logging	99
Max/Min Mode
Data Hold
USB
Display Backlight
Full Icon Display
Sleep Mode
Low Battery Display
Input Impedance for ACVoltage Measurement	≥10MΩ
Max. Display	9999

GENERAL CHARACTERISTICS

Power	1.5V Battery (LR16) × 4
LCD Size	46 mm x 42 mm
Product Color	Red and Grey
Product Net Weight	601g
Product Size	303 x 112 x 39 mm
Standard Accessories	4pcs of Test Lead, Batteries, User Manual, 4pcs of Alligator Clips, USB Interface Cable, Software, Tool Box
Standard Individual Packing	Gift Box
Standard Quantity Per Carton	5 pcs
Standard Carton Measurement	480 x 372 x 315mm (0.056 CBM Per Standard Carton)
Standard Carton Gross Weight	12 kg
