	DVB-T Digital TV Receiver for Cars (MPEG-2) Easy Install: A lot of thought went into making this digital TV box easy to use. In fact this is all you have to do to get it working: Attach the extra long magnetic DVB-T antenna to the digital TV box Attach one end of the included AV cable to this digital TV box and the other end to your car DVD player's AV in port Connect the unit's power cable to your car battery Start watching digital TV on your car DVD player screen! At a Glance... DVB-T digital TV Attaches to your car DVD player Easy to install Movies, TV shows, news 3 meter magnetic antenna Remote control included Plays AV files from USB drive Manufacturer Specifications Primary Function: DVB-T digital TV receiver Specifications: Receiving frequency: VHF-H (174MHz~230MHz), UHF (470MHz~862MHz) Bandwidth: 8MHz Input level: -78dBm ~ -20dBm Input resistance: 75Ω Demodulator: - Wave: CODFM - Demodulation: QPSK, QAM16. QAM64 - Mode: 2K, 8K - Protection gap: 1/4, 1/8, 1/16, 1/32 - Code rate: 1/2, 2/3, 2/4, 5/6, 7/8 Video Decoding: - Standard: ISO/IEC 13818-2 MPEG-2 MP@ML - Video format: 4:3, 16:9 - Resolution: max. 720*576 Demultiplexer: - Standard: ISP/IEC 13818-1 - Max. input code current: 60Mbps (serial connection) / 7.5MBps (parallel connection) Audio Decoding: - Standard: ISO/IEC 13818-3 - Channel mode: left, right and stereo - Sampling frequency: 32KHz, 44.1KHz, 48KHz Microprocessor: SUNPLUS SPHE1002 Video Output: - Output system: 720 x 480 (NTSC) / 720 x 576 (PAL) - Output level: 1.0Vpp - Output resistance: 75Ω Video player format: AVI Audio player format: MP3 Speed Rating: 150 km/hr Antenna impedance: 50 ohm Working Temperature: -20 C to 70 C Humidity: 80% Media storage: USB flash drive (up to 16 GB) OSD Languages: English Certifications: FCC, CE Manufacturer Ref: RG8IE7RX47FM Product Notes This product supports the DVB-T digital TV standard, which is not used worldwide. Please check to see if DVB-T will work in your region: [http://en.wikipedia.org/wiki/DVB-T] This DVB-T product receives MPEG-2 encoded signals. Please check whether your region's Digital TV broadcasts are MPEG-2 type or MPEG-4 before purchasing this product. This digital TV box is for in-car use Easy to setup Also comes with a USB slot to play AVI and MP3 files from USB flash drives Great addition for older or basic car DVD players Package Contents for CVOC-C46 DVB-T digital TV box Magnetic antenna (3 meters long) Power cable AV cable User Manual - English FAQ - Frequently Asked Questions How can I tell if this will work with my existing car DVD player? If your unit has an AV in port then this digital TV box with work with it. What is the way to power this DVB-T? Where to plug the power cable? The Power Adapter has red and black terminals for connection to your car's battery.
