	4 Channel DVR Security System (Compact Design, H.264 Compression) At a Glance... 4 Channel Simultaneous Recording/Viewing Motion Detection / Alarm Detection H.264 video compression Support remote access through LAN or WAN Great DVR at a great price Manufacturer Specifications Main Function: 4 Channel Digital Video Recorder (DVR) Video Specifications Video System: PAL, NTSC Video Compression: h.264 Video Standards: PAL (360x288, 100 fps), NTSC (360x240, 120 fps) Number of Camera Inputs: up to 4 Video Display: Single or 4 Cameras Recording Mode: Manual/Remote/Motion Detection/Timing Input: - Video Input: 4 x BNC Connector, 1.0V p-p/75 Ohm - Audio Input: 1 x RCA, 200 – 2800mV, 30Kohm Output: - Video: 1 channel TV output, BNC, 1.0Vp-p, 75 Ohms - Video VGA - Audio: 1 Channel RCA, 200-3000mV, 5Kohm Network Specifications Ethernet: Wired RJ-45 (10M/100M) Network Protocol: TCP/IP, UDP, HTTP, NTP, DHCP, DDNS Network Function: IE Remote Monitor, Control, Setup, Playback CMS: YES (Maximum 16 Different I Addresses) General Specifications Color: Black Remote Control: YES Mouse Control: YES Dimensions: L: 220 x W: 210 x H: 44 mm Certification: CE, FCC, RoHS Product Notes Comes with full featured remote controller You can easily change the BNC connection to an RCA AV type with a simple BNC to RCA coupler adapter H.264 compression to maximize recorded video quality If you are looking for DVR sets complete with 4 x Cameras and 500 GB HDD, please check out I39, I40, I41 or I42 If you are looking for 8 Channel, 16 Channel dual stream DVR, please check out CVSH-E176, CVSH-I145 User and Password for the software can be found in the user manual Package Contents 4 Channel DVR Power Cable Remote Controller User Manual Software CD Screws USB Mouse
