Set to light body, the appearance of small, feel comfortable and easy to carry, reliable performance for a multi-function wireless walkie-talkie. To his waist in the same system can work easily. Its innovative design, stability and reliability of the circuit, two-row dot matrix display a variety of colors and the background lights are designed to highlight humanity, is your ideal of a walkie-talkie.
Specifications:
A. operating temperature: -20℃~+60℃
B. Communication System : Simplex or Double Frequency Simplex
C. Dimension(H×W×D): 101mm×54mm×34mm
D. Weight: 1100g (with packing)
E. TX Power: 1W / 2W / 4W / 5W
F. Modulation Type: FM(F3M)
G. Frequency Deviation: ≤±5 KHz
H. Spurious Emission: <-65dB
I. TX Current: 2W(0.7A)/5W(1.5W)
J. Frequency Stability:+-2.5ppm
K. RX Sensitivity:<0.18UV
L. Audio Output Power: ≥500 mW
M. Standby Current: 46mA(Power Save Condition :20mA)
1. New Style Dot Matrix LCD Display
2. FM Radio(Option)
3. 199 memory channels
4. Full-function keypad
5. Sound Alarm
6. Emergency Alarm
7. Keypad Lockout
8. Channel Annunciation
9. Compact Size and Light Weight
10. Wider Band Coverage: It is available on 136-174MHz or 400-470MHz, please note: it can only be available on one of them, please tell us which specification you need when payment, otherwise we will ship it randomly)
11. Low Battery Alert: When the battery power is low, the working status indicator flashes red, reminding you to recharge or replace the battery.
12. PC Programmable: With the optional programming cable, the parameters on radio could be configured by PC software.
13. Large Capacity Li-ion Battery: The 2000mAh Li-ion battery prolongs the stand-by time and talking time, and avoids those accidents and possible danger in general battery.
14. CTCSS/DCS
50 groups of standard CTCSS and 104 groups DCS are available (PC programmable). Built-in CTCSS/DCS Encoder/Decoder can prevent co-channel interference and unwanted conversations on the same frequency and ensure smooth communication.
15. High/Low Power Switchable
The user can transmit signals in high or low power according to the actual needs. When in communication, transmitting in low power can reduce power consumption.
16. Auto Power-saving
Auto power-saving provides longer transmission and stand-by time.10 seconds after no signal or operation, the auto power-saving is activated to minimize power consumption. It resumes to normal mode while receive signals or being operated.
17. Channel Spacing Selectable: Different channel spacing 25 kHz/ 12.5 kHz is editable to conform to the regulations of different countries.
18. Busy Channel Lockout (BCLO): BCLO is used to prevent the interference with the on-going conversation. If BCLO is ON the radio could not transmit on the busy channel.
19. Squelch Level Programmable: Squelch reduces background noise and improves sound quality. Adjustable squelch level makes the radio widely used in various environments.
20. Voice-operated transmission (VOX)
The internal VOX provides PTT control with the simple talking, which brings much convenience for specialized tasks and events where hands-free, constant or repetitive communications are necessary.
21. Multiple Scanning
Scan channel is convenient for the team leader to monitor the on-site situations. The scanning mode and scanning priority is programmable.
23. Time-out Timer (TOT)
When TOT is on and the transmission exceeds the preset time limit, the communication will stop after warning tone. TOT can prevent the radio from any potential damage caused by overlong transmission.
24. Monitor: To monitor whether the current channel has signal, press the MONI key. The Monitor function is used to receive weak signal.
25. Wired Clone: To quickly set the parameters on a radio, you can clone the radio data from another radio with the supplied data cable, saving the time of parameter setting.
26. Squelch Tail Elimination
27. Wide Communication Range and Coverage
High transmit power accommodates wide communication coverage. Even if you are in lift, basement or building, the CN-3022 will bring you prompt and reliable communication. High transmit power accommodates wide communication coverage up to 8Km in open area.
28. High-quality Audio
Audio quality is critical for effective communications. The speaker delivers crisper, clearer and stronger audio because of improved acoustic mechanics, allowing users to continue communicating even in noisy and harsh conditions.
29. Keypad/LCD Back-lit Switch: The backlit of LCD and keypad could be switched on or off for night time operations or less power consumption.
30. One-key Emergency Call
Orange emergency button on top of the radio enables prompt call for help under critical circumstances.
Package Contents:
2x Way Long Range Talkie Walkie FM Radio Interphone Alarm (2 units)(DCWT0455)
1 x User Manual
1 x Warranty Card
1 x Power Adapter
1 x Screw pack
