CPU
º Socket AM3 socket for AMD Phenom™ II processors
º Socket AM2+ socket for AMD Phenom™ II / Phenom™ / Athlon™ FX / Athlon™ / Sempron processors
º Support 95W Phenom™ II X6 processors
º High-performance HyperTransport 3.0 CPU Interface
º Support transfer rate up to 5200 mega-transfers per second

CHIPSET
º AMD® 785G & AMD® SB710
º North Bridge: AMD® 785G
º South Bridge: AMD® SB710 (multi CPU core unlock feature).

GRAPHICS
º On Chip (AMD 785G-based with ATI™ Radeon HD4200 graphics, Hybrid Crossfire compatible for 75% graphics boost.)
º Integrated DirectX10.1 graphics processor
º Share Memory: Maximum up to 512MB

MEMORY
º Dual-channel DDR2 1066 memory architecture
º 2 x 240-pin DDR2 DIMM socket support up to 16 GB*
º Support DDR2 1066/800/667/533/400 DDR2 SDRAM *
º *(Due to the DRAM maximum size is 2GB at present, the memory maximum size we have tested is 4GB)

EXPANSION SLOT
º 1 x PCI Express x16 Gen2.0 slot
º 1 x PCI Express x1 slot
º 2 x PCI slots

STORAGE
º Support by AMD® SB710
• 2 x Ultra DMA133/100/66 devices
• 6 x Serial ATA 3.0Gb/s devices
• RAID0, RAID1, RAID10 configuration

AUDIO
º VIA® VT1705 6-channel audio CODEC
º Compliant with HD audio specification

LAN
º Atheros AR8131 Gigabit Fast Ethernet Controller (AR8132 10/100 Lan optional)
